Technical Parameters

Voltage: AC100-240v 50-60HZ

Rated power: 550W

Light source: 7 pieces of 60W (four-in-one RGBW) high-brightness LED beads

Filament backlight: 12 3W (three-in-one RGB) LED tungsten filament pixel strips

Beam tinting angle: 7 – 45˚

Strobe: 1-25 times/second, with multiple strobe effects

Dimming: 4 dimming effects (Linear/Square/ISquare/Scurve) with 0-100% linear dimming,

Channel: Built-in 6 channel modes 21/30/36/57/78/93CH

Control: DMX512, self-propelled, RDM, supports additional installation: Art-Net, wireless signal reception

Horizontal scanning: 540 degrees + 16-bit fine adjustment, Vertical scanning: 270 degrees + 16-bit fine adjustment

Optical effect: Creates a softer tinting range. The latest Aura features a tungsten filament pixel effect.

Color: RGBW offers a vibrant and dynamic mix of bright, saturated colors, as well as soft pastels and white tones. Virtual colors

Dynamic display, tungsten filament pixel simulation effect

Effect Backlight Macro: Multiple built-in macro effects, allowing control over foreground color, background color, speed, and direction. Fixed device beam pixels and Aura

3D video mapping of the filament. Effects such as high-speed scanning, tilting and zooming, marathon, flowing water, and whirlwind.

Display screen: Chinese and English protection, IP20

Temperature control: Intelligent temperature control, capable of automatically adjusting the speed of the cooling fan and providing overheat protection, along with an intelligent defogging system

Shell material: The latest third-generation structural waterproof design, featuring a metal die-cast aluminum shell combined with fire-resistant and UV-resistant engineering plastic

Protection level: IP20

Lamp size: 35.6*28*45cm

Carton packaging (one piece per carton): 43.5*36*52.5cm

Net weight: 14.6kg Gross weight: 18.5kg
